The Philips IntelliVue MX700 is an advanced patient monitoring system designed to provide an enhanced and immediate display of vital signs for your patients. This bedside monitor includes a built-in PC option, known as iPC, which seamlessly integrates with your hospital's intranet and applications, offering a wealth of clinically relevant information. Additionally, the MX700 monitor can easily connect to the Philips Multi-Measurement Module (MMS) and IntelliVue gas analyzers, expanding its functionality with convenient plug-and-play capability. Moreover, tailored configurations are also available for anesthesia, Critical and cardiac, as well as neonatal care settings.

FEATURES:

• Offers a wide 15" touchscreen, and can also be operated by Navigation Point control and remote control
• Optional integrated PC provides immediate and seamless access to comprehensive patient information
• Highly configurable, widely scalable, and fully compatible with existing IntelliVue solutions
• Smooth surfaces and minimal seams help to support efforts in reducing the risk of cross-contamination

SPECIFICATIONS:

• Manufacturer: Philips
• Part Number: (OEM): MX700

• Category: Patient Monitor
• Condition: Refurbished
• Weight: 10.0 lb.
• Warranty: 12-Months


• Dimensions:
• Width: 15.43 in (392 mm)
• Height: 12.63 in (321mm)
• Depth: 6.41 in (163 mm)
• Weight: <20.9lbs (<9.5 kg)


• Operating & Storage Temperatures:
• Temperature Range Operating: 0 to 40° C (32 to 100° F) with iPC installed: 0 to 35°C (32 to 95°F)
• Temperature Range Storage: -20 to 60° C (-4 to 140° F)
• Humidity Range Operating: 15 % to 95 % Relative Humidity (RH) (non condensing)
• Humidity Range Storage: 5 % to 95 % Relative Humidity (RH)
• Altitude Range Operating: -500 m to 3000 m (10000 ft)
• Altitude Range Storage: -500 m to 4600 m (15000 ft)


• Display:
• Size: 15 in
• Type: 389 mm active matrix color LCD (TFT)
• Resolution 1280 x 768
• Refresh rate 59.9 Hz
• Useful screen 334 x 200.45 mm
• Pixel size 0.261 x 0.261
• Resolution 1280 x 768
• Refresh rate 59.9 Hz
• Useful screen 334 x 200.45 mm
• Pixel size 0.261 x 0.261


• Performance:
• Power Consumption <200 W average
• Line Voltage 100 to 240 V
• Current 1.9 to 0.9 A
• Frequency 50/60 Hz


• Sound:
• Audible feedback for user input
• Prompt tone
• QRS tone, or SpO2 modulation tone
• 4 different alarm sounds Remote tone for alarms on other beds in network
• Tone for Timer expired


• Network:
• Standard 100-Base-TX (IEEE 802.3 Clause 25)
• Connector RJ45 (8 pin) Isolation basic
• insulation (reference voltage: 250 V; test voltage: 1500 V)


• RS232 (Standard):
• Connector RJ45 (8-pin)
• Power none
• Isolation basic insulation (reference voltage: 250 V; test voltage: 1500 V)


• USB Interface (4 Ports):
• Standard USB 2.0 full-speed (embedded host)
• Connector USB series “Standard A” receptacle
• Power Low power port 4.4 V min; max. load for all ports together 500 mA
