The GE Carescape B650 is an exemplary patient monitor that seamlessly integrates the finest features from both the Marquette and Datex-Ohmeda platforms into a singular device. With its advanced capabilities, the CARESCAPE B650 effectively measures various standard parameters such as ECG, SpO2, NIBP, and patient temperature. Moreover, this system goes beyond the basics by offering state-of-the-art tools for measuring O2, CO2, N20, and anesthesia agent analysis. These advanced functionalities render the patient monitor highly suitable for a diverse range of medical settings including Critical Care, Recovery Rooms, Neonatal Intensive Care Units, Intensive Care, and Operating Rooms.

The Ge Carescape Monitor boasts a vibrant 15-inch LCD color display that features a backlight, ensuring optimal visibility. It is available in both touchscreen and non-touchscreen options, catering to individual preferences. Furthermore, the B650 system has the capability to store up to 24 hours of trending data, enabling comprehensive analysis and tracking of patient information. Additionally, it can record up to 36 arrhythmia events, providing valuable insights for medical professionals.

FEATURES:

• Works with many existing Marquette and Datex-Ohmeda Components
• 15 inch LCD touch screen display with a pivotal frame
• Dedicated software and parameters for Anesthesia, PACU, Critical Care, Emergency care and NICU
• User-controlled views from 8-14 waveforms with overlays and insteps
• Full Data Connectivity with the Carescape Patent Data Module for seamless patient data Capture in HIS/EMR
• Integrated USB ports for a keyboard, mouse, barcode reader and other data entry device attachments

SPECIFICATIONS:

• Manufacturer: GE
• Part Number: (OEM): B650

• Category: Patient Monitor
• Condition: Refurbished
• Weight: 21.6lbs.
• Warranty: 3-Months


• Dimensions:
• Height: 14.2” (36 cm)
• Width: 14.6” (37 cm)
• Depth: 8.67” (22 cm)
• Weight: 21.6lbs (9.8 kg)


• Battery:
• Type: Exchangeable Lithium-Ion
• Voltage: 11.1V (nominal)
• Capacity: 6.21Ah (typical)
• Charge Time: 2-3 hours, depending on configuration
• Run Time: 1-2 hours, depending on configuration
• Battery Life: 150 cycles to 80% capacity


• Display:
• Size: 15” (38.1 cm) diagonal
• Type: Active matrix color TFT LCD
• Resolution: 1024 x 768 pixels (XGA)
• Number of Traces: 8 individual, up to 14 with overlays and insets
• Sweep Speed: 0.25, 6.25, 12.5, 25, 50 mm/sec


• I/O Connectors:
• Ethernet: 1 RJ45 for monitor network, 3 optional Rj45 for HIS, service, and Unity Network ID
• E-Port: 1 optional DB9F, for CARESCAPE Patient Data Module
• Display: 1 DVI out (VGA with adapter)
• USB Port: 2 USB 2.0, 2 optional USB 2.0


• Mounting:
• GCX Compatible
• FM Quick-Mount Compatible
• Integrated Carrying Handle


• Paper Recorder (Optional, Built-in):
• Method: Thermal dot array
• Horizontal Resolutions: 24 dots/mm (600 dpi) @ 25 mm/sec
• Vertical Resolution: 8 dots/mm (200 dpi)
• Number of Waveform Channels: 4
• Paper Width: 50 mm (2”)
• Paper Length: 30 m (100 ft)
• Paper Speed: 1, 5, 10, 12.5, 25, and 50 mm/sec


• Controls:

• Trim Knob Control: Standard
• Touch screen: Optional, resistive technology
• Hard Keys: 3 standard keys: ON/Standby, Home, Pause Audio Alarm 11 additional keys in non-touch version: Trends, Monitor Setup, Data & Pages, Alarm Setup, Procedures, Print Waveforms, Freeze/Snapshot, NIBP Auto, NIBP Start/stop, Parameters, Zero All Pressures
• Remote control Ordered separately


• Pivoting Module Frame:
• Features: Can be pivoted to a locked closed position, locked to an open 45° angle, or locked to a 90° open position. Support for CARESCAPE Patient Data Module or Patient Side Module
• Options: Two optional E-module slots and optional recorder


• Patient Side Module (E-PSM, E-PSMP):
• ECG: 3, 5, 6 and 10 leadwires
• SpO2: GE SpO2
• NiBP: GE GE
• InvBP: 0 or 2
• Temp 2


• CARESCAPE Patient Data Module (PDM):
• 3, 5, 6 and 10 leadwires
• SpO2: Masimo SET, Nellcor OxiMax
• NiBP: GE DINAMAP SuperSTAT algorithm
• InvBP: 0 or 4
• Temp: 2, Optional with C.O.
• Cardiac Output: Optional with temperature


• Software Options:
• Main Software: Care-area specific software packages to optimize workflows: OR, PACU, ICU, ED, NICU
• Other Software Options: Extended software options specific to each main software package


• Alarms:
• Categories: Patient status and system status
• Priority: 3 levels – High, Medium and Low, In accordance with IEC 60601-1-8
• Notification: Audible and visual
• Setting: Default and individual
• Visual Alarm Notification: Red, yellow, cyan
• Audio Pause: 2 or 5 minutes
• Volume: 79 dB(A) (max) measured at 1m, high priority alarm


• Power Specifications:

• Universal Input Voltage Range: 100 to 240 Vac +/-10%, 50/60 Hz
• Power Consumption: 140 VA (max)
• Protection Class: Class I
• Grounding: Hospital grade
• Cooling: Natural convection, no fans


• Operating Conditions:
• Temperature: 10°C to 35°C (50°F to 95°F)
• Relative Humidity: 10% to 90% non-condensing


• Storage Conditions:
• Temperature: -20°C to 60°C (-4°F to 140°F)
• Relative Humidity: 10% to 90% non-condensing
